Pool pump Aspire 2 Three-phase

Name: Pool pump Aspire 2 Three-phase
Brand: BAEZA
SKU: 000BP0009
Price: 309 EUR
Availability: InStock

BAEZA

Referencia: 000BP0009

Thanks to its powerful motor three-phase and and its design hydraulic optimised, the pumps ASPIRE 2 three-phase guarantee a flow rate constant and a pressure eleved, even in conditions of working exigentes. Its capacity to adapt a different applications, together with with its ease installation and maintenance, making it a solution versatile and reliable for any proyecto.

Body: Constructed in tecno polymer, resistant to the chemical products and to the UV rays.
Shaft: Manufactured in AISI-316 stainless steel, it that ensures a high resistance to the corrosion and to the abrasion.
Sellos mechanical: Utilizamos sellos mechanical of carbono/ceramic, designed to withstand altas temperatures and presiones, ensuring a watertightness perfect.
Motor: Motor single-phase of high efficiency, with protection thermal included to prevent sobrecalentamientos.

€309.00 IVA incluido

Quantity

Pídalo antes de 13:00 de mañana y recíbalo entre Thu 16 July y Mon 20 July
*See information regarding the delivery time

The range ASPIRE 2 of pumps self-priming is designed for satisfacer the requirements more exigentes of recirculation and water filtration in pools. With an innovative design and high-quality materials, these pumps offer an exceptional performance and a long durability in environments exigentes.

Equipped with Motors three-phase of high efficiency IE3 and features advanced, the pumps ASPIRE 2 guarantee a quiet operation, safe and efficient. This range includes options adapted a different Power outputs and requirements of flow rate, ensuring that always haya a solution ideal for each pool.

features, Benefits and Benefits of the Pumps Self-Primings three-phase ASPIRE 2 of Aquallice

Autoaspiration up to 3 metres, ideal for installations with conditions desafiantes.
Motor asynchronous of 2 poles with protection IPX5 and insulation class F, ensuring durability and reliability.
manufacture in tecno polymers resistant to corrosion, adecued for use in environments wet.
mechanical seal in alumina-grafito to minimise the wear and ensure a sealing optimum.
quiet operation for an environment more comfortable and pleasant.
Compatible with systems electrical of 230/380 V, it that facilitates its integration in installations existentes.
Easy maintenance thanks to its modular design and parts Accessible.

Comparative of Models of the Pumps Self-Primings three-phase ASPIRE 2 of Aquallice

Model	Reference	Power (CV)	Power (kW)	Flow Rate (l/h a 10 m.c.a.)	Maximum Head (m)	Amperios	Voltage (V)	Connections (mm)
ASPIRE 2 75 T	130230	0,75	0,55	17.500	16,5	3,6/2,1	230/380	63
ASPIRE 2 100 T	130232	1	0,9	25.000	20	4,5/2,6	230/380	63
ASPIRE 2 150 T	130234	1,5	1,1	27.500	19,5	6/3,5	230/380	63
ASPIRE 2 200 T	130236	2	1,5	33.000	22	7,1/4,1	230/380	63
ASPIRE 2 300 T	130238	3	2,2	38.500	25	9/5,2	230/380	63

Instructions of Use of the Pumps Self-Primings three-phase ASPIRE 2 of Aquallice

Before of the installation, ensure of which supply electrical this desconected.
Instale the pump in a Dry place and well ventiled, preferiblely to the sombra to prevent Exposure direct to the sun.
Conecte the pipes of suction and discharge Ensuring of that are well selled to prevent leaks of air.
Verifique which supply electrical coincida with the especifications of the pump (230/380 V).
Active the pump and purgue the system to remove any burbuja of air that can afectar the performance.
Realice mantenimientos regular to clean the pre-filter and verificar the condition of the gaskets and connections.
If Note ruidos inusuales or disminution in the flow rate, apague the pump and revise possible blockages or damage.
